professional manufacturer in the field of wire and cable assembly
3 Years
| Ask Lasest Price | |
| Brand Name : | XSD Cable |
| Model Number : | Single Conductor Wire |
| Certification : | UL,CE,ISO:9001 |
| Price : | Negotiate |
| Delivery Time : | 7-30days |
| Payment Terms : | T/T |
| Supply Ability : | 1000000Meter/month |
| Attribute | Value |
|---|---|
| Product Name | Single Conductor Wire |
| Ul Certification | 2468 |
| Application | General Purpose |
| Rated Temperature | 80°C |
| Stranding | Solid |
| Ul Style | 2468 |
| Color | Black |
| Conductor Strand | Solid |
| Conductor Size | 18 AWG |
| Conductor | Copper |
| Temperature Rating | 90°C |
| Conductor | Insulation | Max. Cond Resistance at 20°C (Ω/km) | |||
| AWG | Construction (No./mm) | Diameter (mm) | Thickness (mm) | Diameter (mm) | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 150 |
| 24 | 7/0.20 | 0.60 | 0.26 | 1.12 | 94.2 |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 59.4 |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 36.7 |
| 18 | 16/0.254 | 1.18 | 0.27 | 1.70 | 23.2 |
| 16 | 26/0.254 | 1.49 | 0.41 | 2.31 | 14.6 |
| 14 | 41/0.254 | 1.87 | 0.41 | 2.70 | 8.96 |
| 12 | 65/0.254 | 2.36 | 0.60 | 3.56 | 5.64 |
| 10 | 66/0.32 | 3.00 | 0.60 | 4.20 | 3.55 |
|
|
